Page #43 background image
Jumper and Connector Description for the 9750 Controller Card Family
www.lsi.com/channel/products 39
J1C1 Reserved for
LSI use.
3-pin connector.
Reserved for LSI use.
J1L1 Remote
battery
backup
unit (BBU)
connector
20-pin connector.
Connects the optional remote intelligent
battery backup unit (LSI iBBU07)
remotely to the controller by cable.
J2B1 4 Lane
SATA+SAS
connector
(Ports 20-23)
SFF-8088 x4 external mini SAS
connector.
Connects the controller by cable to SAS
drives or SATA drives, or a SAS
expander.
J2B2 4 Lane
SATA+SAS
connector
(Ports 16-19)
SFF-8087 x4 internal mini SAS
connector.
Connects the controller by cable to SAS
drives or SATA drives, or a SAS
expander.
J2D1 Standard
PCIe edge
card
connector
x8 PCIe 2.0 bus connection as defined in
the PCI Express specification.
The RAID controller interfaces with the
host system using this connector.
J3B1 4 Lane
SATA+SAS
connector
(Ports 12-15)
SFF-8087 x4 internal mini SAS
connector.
Connects the controller by cable to SAS
drives or SATA drives, or a SAS
expander.
J4A1 CPLD
Module
connector
1x8-pin connector.
Reserved for LSI use.
Table 11: Jumpers and Connectors for 9750-24i4e
(continued)
Jumper/
Connector
Type Description
