Jumper and Connector Description for the 9750 Controller Card Family
www.lsi.com/channel/products 41
J5A2 Write
pending LED
connector
2-pin connector.
Connects to an LED that indicates when
the data in the cache has yet to be
written to the storage devices. Used
when the write-back feature is enabled.
J5B1 LED fault
indication
connectors
for internal
drive ports
(Ports 0
through 7)
2x8-pin connector.
There is one LED connector for each
internal drive port. When lit the LED
indicates the corresponding drive has
failed or is in the unconfigured-bad state.
The LEDs function only in a direct-attach
configuration.
Drive attach is defined as a maximum of
one drive connected directly to each port
with no SAS expander.
J5B2 4 Lane
SATA+SAS
connector
(Ports 0-3)
SFF-8087 x4 internal mini SAS
connector.
Connects the controller by cable to SAS
drives or SATA drives, or a SAS
expander.
J5B3 UART debug
connector
4-pin connector
Reserved for LSI use.
Table 11: Jumpers and Connectors for 9750-24i4e
(continued)
Jumper/
Connector
Type Description
