6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 3: MegaRAID SAS RAID Controller Characteristics
6Gb/s MegaRAID SAS RAID Controller Family
Figure 21 Card Layout for the MegaRAID SAS 9280-24i4e RAID Controller
NOTE Pin 1 on the headers and connectors is highlighted in red in the previous figure.
NOTE The MegaRAID SAS 9280-16i4e RAID controller is like the MegaRAID SAS 9280-24i4e RAID controller
except that the MegaRAID SAS 9280-16i4e controller does not contain the J4A5, J5A1, or J5B2 connectors.
85067-07
J2B1
Ports
0-3
J2B2
Ports
4-7
J3B1
Ports
8-11
J4B2
Ports
12-15
J1A2
J1B1
J1B3
J1B2
Ports 24-27
J1C1
J2D1
J1L1
on
back
J4A2
J5A2
J4A3
J5B3
J4A1
J4A4
J4A5
J5A1
Ports
16-19
J5B2
Ports
20-23

LSI MegaRAID SAS Specifications

General

RAID Levels	0, 1, 5
Ports	8
Form Factor	Low Profile
Operating Systems Supported	Windows, Linux, VMware
SAS Ports	8
BBU Support	Optional
Operating Temperature	0°C to 55°C
