LSIS LSLV-G100 User Manual

Code
Comm.
Addres
s
Name
Setting Range
Initial
Value
Prop
erty*
V/
F
S
L
Ref.
In-67
0h1543
P3 terminal
function
setting
4
External Trip
5: BX
X
O
O
p.186
5
BX
p.197
In-68
0h1544
P4 terminal
function
setting
6
JOG
3: RST
X
O
O
p.113
7
Speed-L
p.71
In-69
0h1545
P5 terminal
function
setting
8
Speed-M
7: Sp-L
X
O
O
p.71
9
Speed-H
p.71
11
XCEL-L
p.80
12
XCEL-M
p.80
13
RUN Enable
p.119
14
3-Wire
p.117
15
2nd Source
p.101
16
Exchange
p.154
17
Up
p.115
18
Down
p.115
20
U/D Clear
p.115
21
Analog Hold
p.70
22
I-Term Clear
p.125
23
PID Openloop
p.125
24
P Gain2
p.125
25
XCEL Stop
p.85
26
2nd Motor
p.152
27
U/D Enable
-
33
Baseblock
-
34
Pre Excite
p.94
38
Timer In
p.160
40
dis Aux Ref
p.109
46
FWD JOG
p.115
47
REV JOG
p.115
49
XCEL-H
p.80
51
Fire Mode
p.103
