Code
Comm.
Address
Name
Setting Range
Initial
Value
Property*
V/F
SL
Ref.
buffering stop
level
Cn-80
28
0h1450
Energy
buffering P
gain
0–20000
1000
O
O
O
p.140
Cn-81
28
0h1451
Energy
buffering I gain
1–20000
500
O
O
O
p.140
Cn-82
28
0h1452
Energy
buffering Slip
gain
0–2000.0%
30.0
O
O
O
p.140
Cn-83
28
0h1453
Energy
buffering
acceleration
time
0.0–600.0 (s)
10.0
O
O
O
p.140
8.6 Input Terminal Block Function Group (PAR→In)
In the following table, data shaded in grey will be displayed when the related code has
been selected.
SL: Sensorless vector control (dr.09), Property: Write-enabled during operation
Code
Comm.
Addres
s
Name
Setting Range
Initial
Value
Prop
erty*
V/
F
S
L
Ref.
In-00
-
Jump Code
1–99
65
O
O
O
p.42
In-01
0h1501
Frequency for
maximum
analog input
Start frequency–
Maximum
frequency(Hz)
Maximum
frequency
O
O
O
p.61
In-02
0h1502
Torque at
maximum
analog input
0.0–200.0 (%)
100.0
O
X
X
-
In-05
0h1505
V1 input
voltage
display
-12.00–12.00 (V)
0.00
-
O
O
p.61
In-06
0h1506
V1 input
polarity
selection
0
Unipolar
0:
Unipolar
X
O
O
p.61
1
Bipolar
In-07
0h1507
Time constant
of V1 input
filter
0–10000 (ms)
100
O
O
O
p.61
In-08
0h1508
V1 Minimum
input voltage
0.00–10.00 (V)
0.00
O
O
O
p.61
