LSIS S100 Series Troubleshooting Manual

1. Basic Checklist
10
1.2 Basic Operations
 Display keys
Refer to the following illustration to identify part names and functions.
Key
Key name
Function Description
❶
7-segment display
Displays running condition and parameter information.
❷
SET lamp
Flickers when setting parameter or the [ESC] key is multi-functioning.
❸
RUN lamp
Turns on when running and flickers when accelerating or
decelerating.
❹
FWD lamp
Turns on when motor is operating in forward direction.
❺
REV lamp
Turns on when motor is operating in reverse direction.
The following table describes how the numbers and alphabets are displayed on the keypad.
0
0
A
A
K
K
U
U
1
1
B
B
L
L
V
V
2
2
C
C
M
M
W
W
3
3
D
D
N
N
X
X
