LSIS S100 Series Troubleshooting Manual

2
Contents
INTRODUCTION 3
PRODUCT IDENTIFICATION 4
ASSOCIATION MANUAL 4
SAFETY INFORMATION 5
REVISION RECORD 7
1
BASIC CHECKLIST 8
1.1 Before You Think It Failed 8
1.2 Basic Operations 10
1.3 Change Parameter 12
1.3.1 Change Carrier Frequency 12
1.3.2 Initialize All Parameters 13
1.3.3 Read and Write Parameters 14
1.4 Monitor Fault Trip 15
2
TROUBLESHOOTING 17
2.1 Trips and Warnings 17
2.1.1 Failure/Warning List 18
2.1.2 Troubleshooting Fault Trips 20
2.2 Troubleshooting Other Faults 26
3
MAINTENANCE 32
3.1 Regular Inspection List 32
3.1.1 Daily Inspections 32
3.1.2 Annual Inspections 33
3.1.3 Bi-Annual Inspections 34
3.1.4 Check Input/Output Module 35
3.1.5 Replace Cooling Fan 39
3.2 Storage and Disposal 42
3.2.1 Storage 42
3.2.2 Disposal 42
