1.3 Change Parameter
1.3.1 Change Carrier Frequency
The following example demonstrates how to configure carrier frequency by modifying CN.4 from
15Hz to 5 Hz. It is possible to configure the parameters for different codes in any other group in the
same method.
Step
Instructions
Keypad Display
1
Shift to CN group 4 code.
2
Press [ENT] key.
Display shows 15 which is the current CN.4 code parameter value.
3
Press [▼] key multiple times until it becomes 5 (wanted value).
4
Press [ENT] key.
The set parameter flickers.
5
Press [ENT] key again to save.
Display shows CN.4. The parameter value has changed.
C N . 4
15
5
0 5
Cn. 4
05
5
15
Cn. 4
