LSIS Starvert iG5A Series User Manual

1) Only displayed when F 4 is set to 1 (DC brake to stop).
2) If H40 is set to 3 (Sensorless vector), Max. frequency is settable up to 300Hz.
3) Only displayed when F24 (Frequency high/low limit select) is set to 1.
LED
display
Address for
communication
Parameter
name
Min/Max
range
Description
Adj.
during run
Factory
defaults
Function group 1
A204
[Stop mode
0 ~ 3
select]
A208
[DC Brake 0.1 ~ 60
start frequency] [Hz]
A209
[DC Brake 0 ~ 60
wait time] [sec]
A20A
[DC Brake 0 ~ 200
voltage] [%]
A20B
[DC Brake time] 0 ~ 60
  [sec]
[DC Brake start 0 ~ 200
A20C
voltage] [%]
A20D
[DC Brake start 0 ~ 60
time] [sec]
[Time for
0 ~ 60
A20E magnetizing
[sec]
a motor]
A214 [Jog frequency]
0 ~ 400
[Hz]
A215 [Max frequency]
40 ~ 400
[Hz]
A216 [Base frequency]
30 ~ 400
[Hz]
A217 [Start frequency]
0.1 ~ 10
[Hz]
A218
[Frequency high
0 ~ 1
/low limit select]
A219
[Frequency 0 ~ 400
high limit] [Hz]
[Frequency 0.1 ~ 400
A21A
low limit] [Hz]
A21B
[Torque Boost
0 ~ 1
select]
A21C
[Torque boost in
forward direction] 0 ~ 15
A21D
[Torque boost [%]
in reverse direction]
0 Decelerate to stop
1 DC brake to stop
2 Free run to stop
3 Power Braking stop
This parameter sets DC brake start frequency.
It cannot be set below F23 - [Start frequency].
When DC brake frequency is reached, the drive holds the output
for the setting time before starting DC brake.
This parameter sets the amount of DC voltage applied to a motor.
It is set in percent of H33 - [Motor rated current].
This parameter sets the time taken to apply DC current to a
motor while motor is at a stop.
This parameter sets the amount of DC voltage before a motor
starts to run.
It is set in percent of H33 - [Motor rated current].
DC voltage is applied to the motor for DC Brake start time before
motor accelerates.
This parameter applies the current to a motor for the set time
before motor accelerates during Sensorless vector control.
This parameter sets the frequency for Jog operation.
It cannot be set above F21 - [Max frequency].
This parameter sets the highest frequency the drive can output.
It is frequency reference for Accel/Decel (See H70)
Caution
Any frequency cannot be set above Max frequency except Base
frequency
The drive outputs its rated voltage to the motor at this frequency
(see motor nameplate).
The drive starts to output its voltage at this frequency.
It is the frequency low limit.
This parameter sets high and low limit of run frequency.
This parameter sets high limit of the run frequency.
It cannot be set above F21 - [Max frequency].
This parameter sets low limit of the run frequency.
It cannot be set above F25 - [Frequency high limit] and below
F23 - [Start frequency].
0 Manual torque boost
1 Auto torque boost
This parameter sets the amount of torque boost applied to a motor
during forward run. It is set in percent of Max output voltage.
This parameter sets the amount of torque boost applied to a motor
during reverse run. It is set as a percent of Max output voltage.
0 X
5.00 X
0.1 X
50 X
1.0 X
50 X
0 X
0.1 X
10.00 O
60.00 X
60.00 X
0.50 X
0 X
60.00 X
0.50 X
0 X
2 X
2 X
F 4
F 8
F 9
F10
F11
F12
F13
F14
F20
F21
F22
F23
F24
F25
F26
F27
F28
F29
2)
3)
1)
27
