LED
display
Address for
communication
Parameter
name
Min/Max
range
Description
Adj.
during run
Factory
defaults
Input/output group
This is the time drive determines whether there is the input
frequency command or not. If there is no frequency command
input during this time, drive starts operation via the mode
selected at I62.
Frame communication time
When the protocol is set, the communication format can be set.
0 Parity: None, Stop Bit: 1
1 Parity: None, Stop Bit: 2
2 Parity: Even, Stop Bit: 1
3 Parity: Odd, Stop Bit: 1
The user can register up to 8 discontinuous addresses and read
them all with one Read command.
The user can register up to 8 discontinuous addresses and write
them all with one Write command
Sets current level to open the brake.
It is set according to H33ʼs (motor rated current) size
I63
I64
I65
I66
I67
I68
I69
I70
I71
I72
I73
I74
I75
I76
I77
I78
I79
I80
I81
182
[Wait time after
A43F loss of frequency
0.1 ~ 120
command]
[sec]
A440
[Communication 2 ~ 100
time setting] [ms]
A441
[Parity/stop bit
0~3
setting]
A442
[Read address
register 1]
A443
[Read address
register 2]
A444
[Read address
register 3]
A445
[Read address
register 4]
0~42239
A446
[Read address
register 5]
A447
[Read address
register 6]
A448
[Read address
register 7]
A449
[Read address
register 8]
A44A
[Write address
register 1]
A44B
[Write address
register 2]
A44C
[Write address
register 3]
A44D
[Write address
register 4]
0~42239
A44E
[Write address
register 5]
A44F
[Write address
register 6]
A450
[Write address
register 7]
A451
[Write address
register 8]
A452
[Brake open 0~180
current] [%]
1.0 O
5 O
O O
5
6
7
8
O
9
10
11
12
5
6
7
8
O
5
6
7
8
50.0 O
1) It is indicated when choosing I54~I55 as a 19 (Brake signal).
1)
iG5A
Function List
