Digital Video Recorder User Manual
107
Appendix D 4-CH Specifications
Compression format Standard H.264 Baseline
Video output
Composite：1.0V p-p/75Ω，BNC×2 , VGAX1
Video input
Composite：1.0V p-p/75Ω，BNC×4
VGA Resolution 1280*1024 /1024*768/ 800*600
Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC)
Display Frame Rate 100FPS (PAL), 120FPS (NTSC)
Record Frame Rate 100FPS (PAL), 120FPS (NTSC)
Audio input -8dB~ 22k, RCA X4
Audio output -8Db~92dB, RCA X1
Alarm input NO or NC 4CH
Alarm output: 1CH
Record Mode Manual / Sensor /Timer / Motion detection
Simplex/Duplex/Triplex Pentaplex
Network Interface RJ45 (LAN, INTERNET)
PTZ control YES
Communication interface RS485, USB2.0 x 2(one for backup, another for USB mouse)
Disk info SATA x 1
Remote controller YES
Power supply 12V3A
