Digital Video Recorder User Manual
13
Item Name Description
1 Video out Connect to monitor
2 Spot out
Connect to monitor as an AUX output channel by channel. Only
video display, no menu show
3 Audio out Audio output, connect to the sound box
4 Video in Video input channels from 1-4
5 DC12V POWER INPUT
6 VGA port VGA output, connect to monitor
7 LAN Network port
8 USB port Connect USB mouse or connect external USB devices
9 P/Z Connect to speed dome
10 K/B Connect to keyboard
11 ALARM OUT 1-ch relay output. Connect to external alarm
12 + 5V and GND +5 V and Grounding
13 ALARM IN Connect to external sensor1-4
14 Audio in 4 CH Audio input
Tab 2.2 Definitions of Front Panel Buttons
The rear Panel interface for 8-ch is shown as Fig 2.5:
