Digital Video Recorder User Manual
55
Fig 4-33 network configuration-sub stream
Step2: select fps, resolution, quality, encode and max bit rate
Step3: user can setup all channels with same parameters, tick off “all”, then to do relevant setup.
Step4: click “default” button to resort default setting; click “apply” button to save the setting; click “exit” button to exit current interface.
Definitions and descriptions of network stream:
Parameter Meaning
FPS Range from: 1-25
Resolution Support CIF and D1
Quality The quality of the clients’ image. The higher the value is, the clearer the record image. Six
