Lucent Technologies Enhanced VR Series Batteries
2 - 2 Product Description Issue 5 December 1998
for Emergency Lighting and Power Equipment, and UL1989,
Standard for Standby Batteries.
Features
• Bell Laboratories’ patented lead/tin alloy post, leakproof
post seal, and valve-regulated design require minimal
maintenance.
• An Enhanced VR battery consists of compact, modular cells
that permit up to 750Ah of 48V battery reserve (at a 10-hour
rate) to be installed in a single VR battery stand.
• The totally front-access, modular design allows easy
installation and growth. In addition, the removable handle
facilitates battery replacement, if required.
• Flame-retardant (UL 94 V-O flammability rating) PPO/PS
jar and cover material together with metal cell sleeves
support longer life by providing jar rigidity for
higher-temperature applications.
• Each 2-volt, 125Ah cell contains a pressure-regulating vent
located in the jar cover. The vent is covered with a porous
plastic disk that acts as a flame arrestor. In multi-cell
configurations, the vents and flame arrestors are hidden
from view by the bus bar cover.
Specifications
Battery Serial
Number
Each battery has its own serial number printed on the front label.
The serial number format consists of a letter code followed by
ten digits. The letter identifies the supplier as well as the
manufacturing location. The first four digits indicate the year
and the month of manufacture; the remaining digits are the serial
number.
L9504123456 means that this battery was manufactured in April
1995, and has a serial number of 123456.
Batteries
Table 2-A outlines the weight, physical dimensions,
ampere-hour rating (measured at the 10-hour rate), and the
recommended float voltages for the Enhanced VR modules.
