Weiver 2.0
/ Operations Manual
70
GPS Graph
Displays current location (latitude, longitude) coordinates updated every second.
The sizes of the Spectrum Graph
, IQ Graph , Power Graph , GPS Graph can be
adjusted at the same time.
IQ Graph ( I:16bits, Q:16bits )
In the capture mode, there is an advantage to capture while the user’s looking at I, Q graphs. I, Q is asigned
16bit integer value (maximum value 32,767, the minimum -32,768) and when transmitting arbitrary I, Q
files created by users, WEIVER will produce the most excellent RF signal when I/Q 16 bit signal has full
swing.
