Weiver 2.0
/ Operations Manual
73
The data les stored in a capture mode are generated in two types(File Name.iqw, File Name.log).
File Name.iqw is stored in the order of [I : 2Bytes, Q 2Bytes], File Name.log includes the records of Name.iqw
le additional information. If File Name.log doesn’t exist, Band Width is represented by the ARB, you can play
the le by typing IQ rate and the Center Frequency .
To play back the captured RF data les. Please go to Playmode and open the list of captured data les.
Click on the File Open button
To delete a saved le, check the box next to the le name and click the
Delete button.
To backup or to copy the les, check the boxes adjacent to the le name
and click the Copy button. Select the save path (e.g., E:\)
To play, check the relevant box adjacent to the le and click the play
button .
To stop play, click on the Stop button.
Play Mode
