21
LEd1
LEd2
LEd3
LEd4
Support of alarm signaling. In
the situation when the support
function is switched on, After the
alarm state retrea, the signaling
diode is not blanked. It signals
the alarm state till its blank-
ing moment by means of the
button com-
bination. This function concerns
only and exclusively the alarm
signaling thus relay contacts will
operate without support accord-
ing to the chosen type of alarm.
oFF – function switched off
on – function switched on
out
Parameter
symbol
Description Range of changes
P_An
Input quantity, which the analog
output has to react on.
InP1 – main input (indicated
value).
Hour – real-time clock.
tyPA
Type of analog output
0_10U – voltage 0...10 V
0_20A – current 0...20 mA
4_20A – current 4...20 mA
AnL
Lower threshold of the analog
output. give the value, on which
we want to obtain the minimal
value of signal on the analog
output.
-19999...99999
AnH
Upper threshold of the analog
output. give the value on which
we want to obtain the maximal
value of signal on the analog
output(10 V or 20 mA).
-19999...99999
Table 5
cd. Table 4
