6.5. Registers for Write and Readout
Table 9
The value is placed in 16-bit registers
write (w)/readout (r)
Input type4000
tYP1
w/r 0...14
Range DescriptionSymbol
0 Pt1 – Pt100
1 Pt5 – Pt500
2 Pt10 – Pt1000
3 rEZL – Resistance, range 400
W
4 rEZL – Resistance, range 4000
W
5 tE-J – J – thermocouple of J type
6 tE-h – K – thermocouple of K type
7 tE-n – N – thermocouple of N type
8 tE-E – E – thermocouple of E type
9 tE-r – R – thermocouple of R type
10 tE-S – S – thermocouple of S type
11 0_10U –
voltage measurement, range 10 V
12 0_20A –
current measurement, range 20 mA
13 0_60n –
voltage measurement, range 60 mV
14 HoUr – current time
Value
Reserved4001 w/r
Reserved4002 w/r
4003
Cnt
w/r 1...3600
Measurement time expressed in seconds. This
time defines the averaging time of the measured
value. The displayed value is the mean value
calculated from the Cnt1 period.
Reserved4004 w/r
Reserved4005 w/r
Reserved4006 w/r
Reserved4007 w/r
