Lumel N30U User Manual

6
2. METER SET
The set is composed of:
- N30U meter ........................................................................1 pc
- User’s manual ....................................................................1 pc
- Guarantee card ..................................................................1 pc
- Set of clamps to fix the meter in the panel .........................4 pcs
- Set of labels with units .......................................................2 pcs
- Seal ....................................................................................1 pc
When unpacking the meter, please check whether the type and execu-
tion code on the data plate correspond to the order.
l signaling of alarm operation – switching the alarm on causes the
highlight of the output number,
l galvanic separation between connections: alarm, supply, input,
analog output, output of the auxiliary supply, RS-485 interface.
Protection grade from frontal side: IP65
Meter overall dimensions: 96 x 48 x 93 mm (with terminals).
The meter casing is made of plastic.
Fig. 1 View of the N30U Digital Meter

Lumel N30U Specifications

General

Brand	Lumel
Model	N30U
Category	Measuring Instruments
Language	English
