Lumens VC-A71P-HN User Manual

18
1
st
Level
Major Items
2
nd
Level
Minor Items
3
rd
Level
Adjustment Values
Function Descriptions
Hue
0~C~15
Adjustable when the Image mode
is set to Custom
Saturation
0~C ~15
Adjustable when the Image mode
is set to Custom
Gamma
0~C~3
Adjustable when the Image mode
is set to Custom
Pan Tilt Zoom
Pan/Tilt Limit
On / Off
Turn on/off the angle limit setting
Pan Right Limit
0~170
Limit the right angle
Pan Left Limit
-170~0
Limit the left angle
Tilt UP Limit
0~90
Limit the upward angle
Tilt Down Limit
-30~0
Limit the downward angle
Pan Flip
On / Off
Activate the reverse Pan direction
Tilt Flip
On / Off
Activate the reverse Tilt direction
Preset Speed
5/ 25/ 50/ 80/ 120/ 160/
200/ 300 deg/sec
Set the rotation speed of the cradle
head when Preset is performed
PTZ Speed Comp
On / Off
Set the Pan/Tilt moving speed to
vary from the zoom position
D-Zoom Limit
x1~x12
Set the D-zoom limit
PTZ Motion Sync
On / Off
When activated, PTZ
synchronization can be achieved by
controlling with the Presets
<Remark> Refer to the Preset speed
setting for this feature. The speed may
be adjusted automatically due to the
difference of PTZ moving range.
D-Effect
Mirror
OFF / Mirror / Flip / Mirror
+ Flip
Set the mode at which the image is
mirror or flipped
Auto Focus
AF Sensitivity
Low / Mid / High
For AF triggering speed, the higher
the speed is, the faster AF is
triggered
AF Frame
Center Area / All Area /
Auto
AF frame setting, when central area
was set as AF frame, focusing will
be on the center of the screen.
When Full Frame was set as AF
frame, focusing will be calculated
based on the full screen
Zoom Tracking
Manual / Curve Tracing /
Zoom Tracking
The focus mode during lens
zooming
(It can be set in the Manual Focus
(MF) mode)
PTZ Assist
On / Off
When PTZ Assist is enabled and
PTZ control is in operation, the
focus performs only once upon
immediate execution. The focus will
not be triggered afterward when the
scene changes
(It can be set in the Manual Focus
(MF) mode)
SMART AF
On / Off
Turn on this function and AF will
mainly focus on the face
Ethernet
DHCP
On / Off
Enable/Disable DHCP setting using
left and right arrow keys and press
[ENTER] to apply setting.
