Lumens VC-A71P-HN User Manual

19
1
st
Level
Major Items
2
nd
Level
Minor Items
3
rd
Level
Adjustment Values
Function Descriptions
IP Address
192.168.100.100
Press [ENTER] to be in modify
mode; select the item to be
modified using the up and down
keys, and modify the value using
the left and right keys or the
numeric keys.
Subnet mask
255.255.255.0
Press [ENTER] to be in modify
mode; select the item to be
modified using the up and down
keys, and modify the value using
the left and right keys or the
numeric keys.
Gateway
192.168.100.254
Press [ENTER] to be in modify
mode; select the item to be
modified using the up and down
keys, and modify the value using
the left and right keys or the
numeric keys.
Audio
Audio In
Line In/ Mic In
Set Audio In
Audio Enable
On / Off
Turn on/off audio output
Audio Volume
0~C~10
Audio Volume Setting
Audio Delay
On / Off
When the audio is not synchronized
with the video, enable this function
to set the audio delay time
<Remark> Supported when NDI|HX
function setting is off
Audio Delay
Time(ms)
-1~-500ms
Set audio delay time
<Remark> Supported when NDI|HX
function setting is off
Encode Type
AAC/ G.711
Set audio encode type
<Remark> Supported when NDI|HX
function setting is off
Encode Sample
Rate
1. 48 KHz(AAC)
2. 44.1 KHz(AAC)
3. 16 KHz(AAC)
4. 16 KHz(G.711)
5. 8 KHz(G.711)
Set the encode type and sample
rate
<Remark> Supported when NDI|HX
function setting is off
System
Prompt
On / Off
Turn on/off the prompt information
on the display
IR Receive
On / Off
When it is Off, the remote control
will not be able to control the
camera. At this moment, turn off
and then turn on the power to
restore control of the remote
control.
Tally Lamp
On / Off
Select to enable or disable Tally
Lamp function.
Tally CMMD Mode
General / Link
Set whether the indicator light is
linked with RS232 command
 General (Not linked): The
indicator light switch and mode
shall be set separately.
 When the indicator light is on
and the default mode is off,
additional command is required
to set the indicator light mode
 Setting the indicator light mode
when the indicator light is off will
not trigger the indicator light
