Lumens VC-A71P-HN User Manual

20
1
st
Level
Major Items
2
nd
Level
Minor Items
3
rd
Level
Adjustment Values
Function Descriptions
 Link:
 When the indicator light is on,
the default mode is red light
 Setting the indicator light mode
when the indicator light is off will
turn on the indicator light
Language
English / Chinese
Initial Position
Last operated / First
default position
Select the camera lens to return to
the last operated position or the first
default position after POWER ON
<Remark> First default position =
Preset 0
Control Device
Encoder / Controller
Control Device setting,
Controller: for joystick
Encoder: for tracking system
Motionless Preset
On / Off
When the function is enabled, the
screen will Freeze when Preset is
executed. Freeze will be released
after Preset is completed.
Control Port
RS-232/ RS-422
Choose whether the control
interface used is RS-232 or RS-422
Protocol
VISCA / Pelco D
Baud Rate
9600/ 38400
Choose the transmission speed of
the control signal
VISCA Address
0~7
The Protocol set to VISCA allows
the camera ID address to be
assigned. Select 0 for automation.
PELCO D Address
1 ~255
The Protocol set to Pelco D allows
the camera ID address to be
assigned.
Genlock - Hor.
Phase
500~C~-500
Set synchronized source
parameters
Output Mode
1. 3840x2160/59.94p
2. 3840x2160/50p
3. 3840x2160/29.97p
4. 3840x2160/25p
5. 1080p/59.94
6. 1080p/50
7. 1080p/29.97
8. 1080p/25
9. 720p/59.94
10. 720p/50
11. 1080i/59.94
12. 1080i/50
Choose the output resolution
Color Space
Standard Profile /
REC.709/ BT.2020
Set the standard for color space
Factory Reset
On / Off
Resume the factory default setting
Status
Display the current setting status
