Lumens VC-A71P-HN - Page 25

25
5.2.2 Camera Setting
No
Item
Function Descriptions
1
Exposure
 Mode: Select exposure mode (Full Auto / Shutter Pri / Iris Pri / Manual)
 Gain Level: Adjust the gain level (adjustable under the “Manual”)
 WDR: Set the level of wide dynamic range (WDR) in order to obtain
better images
 Exposure Comp. Level: Select exposure compensation level
 Iris Level: Adjust the size of iris (adjustable under the “Manual” or “Iris
Priority”)
 Shutter Speed: Adjust the shutter speed (adjustable under the
“Manual” or “Shutter Priority”)
2
White Balance
 Mode: Select the color temperature mode
 One Push WB: Single color temperature execution adjustment
(adjustable only under the “One Push WB”)
 Manual Red/Blue: Manually adjust blue/red color temperature
3
Focus
 AF Sensitivity: Set automatic focus sensitivity
 AF Frame: Set automatic focus range
 Zoom Tracking: The focus mode during lens zooming (can be set in
“Manual”)
 PTZ Assist: Check whether auto focus is enabled if there is any
changes of PTZ (can be set in “Manual”)
<Remark> When PTZ Assist is enabled and PTZ control is in operation, the
focus will be triggered. The focus will not be triggered when the scene changes
 Smart AF: AF will mainly focus on the face
 One Push AF: When the manual focus mode is on, click the button to
perform one auto focus
4
Mirror
 Mirror: Set image mirroring
 Flip: Set the mirror/flip mode
