5.2.6 Setting - Camera
<Remark> Preview pane is not supported when NDI is on
No
Item
Function Descriptions
1
Zoom ratio
Adjust the zoom-in or zoom-out ratio via scroll bar
2
Exposure
 Mode: Select exposure mode (Automatic/ Shutter Priority/ Aperture Priority/ Manual)
 Exposure Comp. Level: Select exposure compensation level
 Gain: The gain limit is adjustable when the exposure mode is set to “Manual”
 Iris: The size of aperture is adjustable when the exposure mode is set to “Manual” or
“Aperture Priority”
 WDR: Set the level of wide dynamic range (WDR) in order to obtain better images
 Shutter Speed: The shutter speed is adjustable when the exposure mode is set to
“Manual” or “Shutter Priority”
 Smart AE: Enable/Disable Smart Exposure; Available when “Focus - SMART AF” is
on (Currently it’s the bet version. Please refer to Web Page Firmware
Update Information for the official version release schedule.)
3
White Balance
 Mode: Select the color temperature mode
 One Push Trigger: One push color temperature is adjustable when the white balance
mode is set to “One Push Trigger”
 Manual Red / Blue: Manually adjust blue/red color temperature
