6
The following label appears on the back of all system components:
Figure 5. FCC Label
Fluidics In the event of a fluid leak, turn off all power to the system and
disconnect all power cords.
Monitor waste levels manually. Do not allow the waste container to
overflow! Empty the waste container each time you fill the sheath
fluid container. Do not place the waste container on top of the
instrument.
Luminex 200 Analyzer
Laser
The Luminex 200 system classifies per FDA 21 CFR 1040.10 and
1040.11 as a Class II laser product consisting of a Class I laser
product (Luminex 200 analyzer) and a Class II laser product
(barcode reader).
Figure 6. Laser Product Class Label
Figure 7. Laser Radiation Caution Label
Warning: If biological samples are tested with the system, use
standard laboratory safety practices when handling system waste.

Luminex 200 Specifications

General

Power Requirements	100-240 VAC, 50/60 Hz
Dynamic Range	3.5 logs
Number of Analytes	Up to 100
Software	xPONENT
Application	Immunoassays, Nucleic Acid Detection, Enzyme Assays
Technology	xMAP (Multi-Analyte Profiling)
Bead Types	Color-coded microspheres
Lasers	2 (532 nm and 635 nm)
Assay Types	Immunoassays, nucleic acid assays, enzyme assays
Sample Volume	12.5 - 50 µL
PMT Detectors	Yes
