Auto Recover:
When auto recovery is enabled the LumiNode will switch back to input one as soon as this is back
available in the network. In this case the warning for the missing backup control source can be ignored.
When auto recovery is disabled, you can congure which protocol is used to trigger the recovery, which
universe and which channel. This can be narrowed down to a specic IP address which will be the only
device able to control the backup recovery.
The red warning triangle is a warning that the process engine cannot be congured without a backup
control source. This is to indicate that the control source has not been congured yet for remote recovery.
As soon as the control source has been congured this triangle will disappear.
When the backup control option is used, the LumiNode will not restore to input one when this becomes
available in the network. To recover, a value between 8-15 (0-255) needs to be send on the control channel
to trigger the recovery.
Patch, Master/Limit and startup buer options are available for this mode.
X-FADE
This mode oers to you to cross fade between two sources. Ideal in a situation where you need to cross
fade between a lighting desk and a media server, the control channel allows you to keep full control on the
speed and smoothness of the transition.
From the X-Fade panel, you can dene the control channel, the protocol and universe number, and the IP
address of the control source. Click on the gearwheel icon to change these parameters.
When the control channel is at zero, source one is in full control, when the control channel is at full, source
two is in full control.
Patch, Master/Limit and startup buer options are available for this mode.
The red warning triangle is a warning that the process engine cannot be congured without a X-Fade
control source. This is to indicate that the control source has not been congured yet for the X-Fade. As
soon as the control source has been congured this triangle will disappear.
Patch, Master/Limit and startup buer options are available for this mode.
SWITCH
The switch functionality provides you with an easy to use tool to remotely select within up to four inputs,
which input can control your rig. By sending dierent values for the switch channel, you’ll be able to select
the relevant input. The switching between inputs does not include any crossfade.
From the switch panel, you can dene the switching channel, the protocol and universe number, and the IP
address of the control source. Click on the gearwheel icon to change these parameters.
The red warning triangle is a warning that the process engine cannot be congured without a Switch
control source. This is to indicate that the control source has not been congured yet for the Switch. As
soon as the control source has been congured this triangle will disappear.
Patch, Master/Limit and startup buer options are available for this mode.
29
