10 TAKING A MEASUREMENT
Note: Before taking a measurement, take 3 ~ 5 deep breaths and relax. In order to obtain
accurate measurement results, remain seated, keep your arm and hands still, and do not
talk during measurement.
fig. 10-1 fig. 10-2 fig. 10-3
1. Insert the tube plug into the air connector on the side of the main body of the device.
2. Pressbutton“O/|”;allsymbolswilldisplayfor2secondsasshowninFig.10-1;youwillhear
twoshortbeeps;then“0”willdisplay.Theautomaticpumpwillthenbegintoinflatethecuff.
Generally the pressure will reach 190 mmHg as shown in Fig. 10-2 before starting to deflate.
3. As the pump then stops inflating and begins to deflate, pressure will decrease gradually, as shown
in Fig. 10-3. During deflation the user’s blood pressure and pulse will be calculated.
fig. 10-4
4. When measurement calculation is complete you will hear a long beep, the remaining air in the cuff
will deflate quickly, and the blood pressure and pulse measurements will display. Date and time
willdisplayalternatelyasshowninFig.10-4;atthesametime,“M1”and“M2”willflashtoremind
the user to record the measurement.
