5
6. Balance control (BALANCE)
Adjusts the relative volume of the right and left channels.
Rotating the control counterclockwise gradually cuts the
volume of the right channel, rotating the control clockwise
gradually cuts the volume of the left channel.
This knob should be set to the center position under normal
conditions, and rotated to make adjustment if necessary.
Adjustment value of the left and right balance can be set
within the range up to –6 dB for each of left and right.
7. Remote control infrared receiver (R)
Receives signals from the accessory remote control.
8. Tone control for treble (TREBLE)
Controls the frequency characteristics of the high-frequency
range.
Setting this control to the center position provides flat fre-
quency characteristics. Rotating this control clockwise
enhances the high-frequency range and rotating this con-
trol counterclockwise attenuates the high-frequency range.
When the line straight button is set to on, this button does
not work.
9. Tone control for bass (BASS)
Controls the frequency characteristics of the low-frequency
range.
Setting this control to the center position provides flat
frequency characteristics. Rotating this control clockwise
enhances the low-frequency range and rotating this control
counterclockwise attenuates the low-frequency range.
When the line straight button is set to on, this button does
not work.
10. Line straight button (LINE STRAIGHT)
Enhances the purity of the sound quality by bypassing the
tone control circuit.
This button toggles the line straight function on and off.
The line straight indicator lights up when the line straight is
set to on.
When the line straight button is set to on, tone control and
loudness do not work.
