45
OPERATORS MANUAL
With the original pre-tension of the clutch the best possible
function is achieved in most driving circumstances. If the clutch
has to be re-adjusted or it has to be controlled, contact your
nearest LYNX dealer/work shop.
CHECKING AND ADJUSTING THE CHAIN TENSION
Chain driven models have a duplex or triplex chain in oil bath. Check
the chain tension and the oil amount in chain case/gearbox regularly.
Checking
Checking the chain tension will be done by measuring the free
motion of driven variator: the longer the free motion - the slacker the
chain.
· Remove the variator cover, draw a mark on the driven variator
with a pen.
· Rotate the driven variator in one direction so that the snowmobile
begins to move. Check the location of your mark. Rotate the
driven variator in other direction until the snowmobile begins
to move in another direction. Measure the free motion lenght.
IBC / BBD
TRA / BBD TRA / IBC
