Chapter 3. General Specifications
3.1 Power Specifications
Power
Input Voltage DC24V
Input Voltage Range DC 20~28V
Consumption Power
TOPRW0500WD Under 12W
TOPRW0700WD Under 12W
TOPRW1000WD Under 15W
Voltage endurance DC 24V, Within 10 ㎳
Insulation Resistance 500V DC, 10 ㏁
3.2 Memory Specifications
Screen Memory 128MB
Backup Memory
512KB : System buffer(5K Word),
Including Alarm/Logging/Recipe
Backup Period Permanent
Real Time Clock Built in(by Battery))
3.3 Environment Specifications
Operation Temperature (℃) -10 ~ +50
Storage Temperature (℃) -20 ~ +60
Operation Humidity (%RH) 0 ~ 90 (No dew)
Atmosphere No corrosive gas
Vibration Endurance Amplitude: 10≤F＜25 ㎐(2G) X,Y,Z each direction(for 30 minutes)
Noise Immunity 1000Vp-p(Pulse width 1 ㎲)
Static Electricity Discharge Connective discharge from EN61000-4-2: ±4 ㎸
Shock Endurance 10G X,Y,Z each direction(for 3 times)
Surge Voltage 500V(Line-Line)
Ground Connection Class 3(Under 100Ω )
Protection Classification Conform to IP65
3.4 Structure Specifications
TOPRW05 TOPRW07 TOPRW10
Weight 0.4 0.72 1.7
Cooling System Natural Air Circulation
Case Material PC(Flameless)
