4.2 TOPRW0700WD
4.2.1 External Dimension
Model F1(mm) F2(mm) S1 (mm) S2 (mm) R1(mm) R2(mm)
TOPRW0700WD 212 145 45.6 39.6 196 126
4.2.2 Front Part Names and Specifications
