SECTION 7 MAINTENANCE AND SERVICING
Form 169000 / 169040 106 Revision D
I. A30-S Headers
NOTE
To prevent binding and/or
excessive wear caused by sickle
pressing on guards, do not
over
grease. If more than 6 to 8 pumps
of the grease gun are required to
fill the cavity, replace the seal in
the sickle head.
High Temperature Extreme
Pressure (EP2) Performance With
1% Max Molybdenum Disulphide
(NLGI Grade 2) Lithium Base.
A30-S HEADER LH SIDE
AUGER DRIVE BEARING (1 PLC)
AUGER SHAFT BEARING (1 PLC)
REEL SHAFT BEARING (1 PLC)
SICKLE HEAD BEARING (1 PLC)
