SECTION 7 MAINTENANCE AND SERVICING
Form 169000 / 169040 115 Revision D
7.6.3 Oiling
Refer to the following illustration to identify the
various locations that require lubrication. See
Section 7.3.2 Recommended Fluids and
Lubricants for proper oil.
Apply oil to upper edge of lower spans when
oiling chains.
SAE 30
OIL KNIFE DAILY EXCEPT IN SANDY SOIL
REEL DRIVE CHAIN (1 PLC)
A30-S HEADER
A30-S HEADER LH SIDE
AUGER DRIVE CHAIN (1 PLC)
