SECTION 7 MAINTENANCE AND SERVICING
Form 169000 / 169040 178 Revision D
7.18.1.3 Maintenance Record: Self-Propelled
Self-Propelled Windrower Header
ACTION: - Check - Lubricate - Change
MAINTENANCE
RECORD
Hour Meter Reading
Date
Serviced By
BREAK-IN
Refer To Section 7.18.1.1 Break-In Inspection: Self-Propelled
100 HOURS OR ANNUALLY
Conditioner Drive Gearbox Lube Level
Wheel Hub Bearings
Wobble Box Bolt Torque
Wobble Box Lubricant Level
END OF SEASON
Refer To Section 6.19 STORAGE
10 HOURS OR DAILY
NOTE: A RECORD OF DAILY MAINTENANCE IS NOT
NORMALLY REQUIRED BUT IS AT THE
OWNER/OPERATOR’S DISCRETION.
Auger Drive Chain (except A40-D)
Hydraulic Hoses and Lines
Hydraulic Oil Level
Reel Drive Chain (except A40-D)
Sections, Guards and Hold-downs
Sickle Assembly
Wobble Box Bolt Torque - First 10 Hours Only
25 HOURS
Sickle Head
50 HOURS
Auger Drive Jackshaft Bearings (except A40-D)
Auger Shaft Bearings
Gauge Roller Bearings
Main Driveshaft Bearings
Tine Bar Bearings (A40-D)
Reel Shaft Bearings
Conditioner Gearbox Oil - First 50 Hours Only
Conditioner Universal Shafts
Roll Pivots
Conditioner Shaft Bearings
Sickle Drive Cross-Shaft
Wobble Box Oil - First 50 Hours Only
1000 HOURS OR 3 YEARS
Conditioner Drive Gearbox Lubricant
Wobble Box Lubricant
To Next Page
