UNLOADING AND ASSEMBLY
Form 169018 15 Revision C
e. Position new batteries on holder (E).
RATING GROUP CCA VOLT MAX. DIMENSION
Heavy
Duty,
Off-Road,
Vibration
Resistant
BCI 31A 750 12
13 x 6.81 x 9.44 in.
(330 x 173 x 240 mm)
f. Install clamp (F) with bolts (G) provided, and
tighten securely.
IMPORTANT
BATTERY IS NEGATIVE GROUNDED.
Always connect starter cable to the
positive (+) terminal of battery and
battery ground cable to negative (-)
terminal of battery. Reversed polarity in
battery or alternator may result in
permanent damage to electrical
system.
g. Attach positive (red) cable clamps (J) to positive
post on batteries, and tighten. Reposition plastic
covers onto clamps.
h. Attach negative (black) cable clamps (H) to
negative post on batteries, and tighten clamps.
i. Move platform back to closed position.
j. Close engine compartment hood.
G
F
G
H
J
E
