PRE-DELIVERY CHECKS
Form 169018 42 Revision C
D. AIR CLEANER
a. Check that air cleaner cap is firmly attached, and
that all clamps are secure.
b. Check spring clamp at back of air cleaner.
c. Check spring clamps on charge air cooling duct
connections (at turbocharger outlet, engine intake,
and inside cooling box).
E. HYDRAULIC OIL LEVEL
a. Turn filler cap counter clockwise to loosen bung,
and remove dipstick.
b. Check that level is between LOW and FULL
marks.
c. Reinstall dipstick, and turn clockwise to tighten
bung.
TYPICAL CONNECTION
HOLD 0.018 in. (0.46 mm)
GAUGE BETWEEN MIDDLE
COILS AND TIGHTEN CLAMP
UNTIL GAUGE IS SNUG
