MAINTENANCE AN D SERVICING
NOTE:
Use high temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2)
lithium base unless otherwise specified.
Figure 4.
10:Every25Hours
A - R oad Friendly Transport
™
Casting Pivot
B - R oad Friendly Transport
™
Wheel Frame P ivot
NOTE:
Use high temperature extreme pressure (EP2) performance with 1% max molybdenum disulphide (NLGI grade 2)
lithium base unless otherwise specified.
Figure 4.11: Every 2 5 Hours
A - Mower Conditioner Lift Linkage – Left B - Mower Conditioner Lift Linkage – Right
147910
12
1
Revision A
