OPERATION
11 . Op erate the hitch swing control lever to ensure the
carrier frame (A) and hitch (B) are locked together.
12. Activate the hazard lights (C) on the mower conditioner.
Check that all lights are working.
13. Ensure that th e slow moving ve hicle sign (D) is visible
from behind the mower conditioner.
Figure 3.86: Transport Mode
14. Once the field to transport conversion (A) is complete,
leave the switch in the upper position (C). Ensu re that
light (B) is NOT illuminated.
For a reference on converting, refer to 7.4 Converting Road
Friendly Trans port
™
Decal, page 273.
Figur
e3.87:RemoteControl
Con
verting from Transport to Field Mode
DAN
GER
Do not convert the machine into, or from, transport mode until you are certain that all people, animals, and
objects are clear of the unit’s rotational range.
WARNING
Ensure cutterbar doors are properly closed before converting the machine from fieldtotransportmodeto
prevent equipment damage.
147910 76 Revision A
