OPERATION
7. Disconnect hydraulic hoses and electrical harness.
Store hose ends and electrical connector in hose
support (A) at front of hitch as shown.
Figure 3.46: Hose Support
8. Pull back c
ollar (A) on drive line, slide coupler off
tractor po
wer take-off shaft, and rest driveline on hook
(not shown
).
Figure 3.47: Driveline
9. Remove
inboard hairpin (A) from lock (B).
Figure 3.48: Inboard Hairpin
147910 55 Revision A
