MacDon R2 Series - Manual Rear Baffle; Positioning Rear Baffle Deflector Fins

R2 Series Clinic Handout 11
Manual Rear Bae
1. Remove lynch pin (A) securing rear bae adjustment lever (B)
to bracket (C).
2. Pull rear bae adjustment lever (B) inboard to disengage
from bracket (C).
3. Position rear bae adjustment lever (B) as follows:
• Move the lever forward to raise the bae
• Move the lever backward to lower the bae
4. Release rear bae adjustment lever (B) so that the tab engages
the hole in bracket (C).
5. Secure bae adjustment lever (B) with lynch pin (A).
1. Deflector fins (A) are located on the underside of the rear bae.
2. To adjust deflector fins (A), use existing bolt and nut (B).
Once adjusted to the desired angle for windrow width, torque nut to 69 Nm
(51 lbf·ft).
3. Repeat for all fins
Positioning Rear Bae Deflector Fins
Note:
An optional In-Cab Electric Remote Bae Adjustment Kit (B6664) is available for R216 headers.
Note:
Fins may interfere with crop flow in large-stemmed crops,
or when using the double windrower attachment. It may be
necessary to remove fins in these conditions.
Deflector fins (A) can be put in storage position by removing
existing nut and bolt and reattaching fins on top of the bae.
