10 ft-lbs
10 ft-lbs
[14 N-m]
5/16”
5/32”
1/8" safety cable clearance
Holes can be oversized
for leveling the mount
1/2" bolt clearance
Use the two holes closest to
the center line of the glulam.
The bracket can be below the bottom
of the glulam if necessary but
is not recommended if it is avoidable.
1.2.2 Rapid Mount Commercial
Glulam (with Glulam Brackets)
This method is recommended for Glulams or wood beams between
4-1/8” or wider. For narrower beams, span across two or more beams
using the Unistrut mounting method.
To Next Page
