© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 50
Rev. Date 040218
3. Airfoil Installation
Remove three (3) screws and the bottom cover. Be careful not
damage the electrical components with the cover removed.
WHEN CYCLING
INCOMING POWER,
WAIT ONE (1)
MINUTE BEFORE
TURNING THE
POWER BACK ON!
CAUTION: RISK OF ELECTRIC
SHOCK. The bus capacitors
discharge to a level below 50V
DC in 1 minute.
Model 370
Low Voltage (Single Phase):
110-240VAC
Before Continuing:
1. Run the power cable to the mounting location.
2. Run the shielded CAT5e cable from the controller to the mount.
Make sure the power cable is on the opposite side of the
mounting surface and ran in the opposite direction (if possible)
from the safety cable and the CAT5e cable.
WARNING: DO NOT RUN FANS WITHOUT AIRFOILS. THE FANS ARE
NOT CONFIGURED TO OPERATE WITHOUT AIRFOILS ATTACHED.
