M5 x 35 mm Grade 8.8
Hex Head Bolt (18)
M5 Shim (18)
41 in-lbs
[4.6 N-m]
5/16” or 8mm
Socket
3. Airfoil Installation
WARNING: To reduce the risk of personal injury, do not bend the
airfoils or airfoil struts when installing the airfoils, balancing the
airfoils, or cleaning the fan. Do not insert foreign objects in between
rotating fan airfoils.
Repeat the steps above until all six blades and retaining links
are in place.
