© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 33
Rev. Date 040218
Hand Tighten
30 ft-lbs
[41 N-m]
9/16”
Be careful of wires
The bolts attaching the Fixed Angle Mount brackets to the
extension tube (bottom left picture) will be torqued after
securing the mount to the building (later on in this manual).
2.1 Fixed Angle Mount
Motor & Extension Tube
Must use Guy Wire Brackets when installing the Fixed Angle Mount.
