© 2018 MacroAir Technologies Toll Free: 866 668 3247 Fax: 909 890 2313 www.macroairfans.com 45
Rev. Date 040218
2.2.3 Fixed Angle Mount Unistrut
9/16”
30 ft-lbs
[41 N-m]
Level mount
WARNING: Do not put too much tension on the safety cable. There
needs to be a small amount of slack present in the safety cable for
proper functioning. Avoid sharp edges.
The safety cable must
be securely attached to
the building structure and
NOT the unistrut. It can
be attached to I-beams,
steel trusses, or Glulams
as shown in sections 1.2.1,
1.2.2 and 1.2.3. Avoid sharp
edges. If you are unsure
how to secure the safety
cable properly, contact a
structural engineer.
Now Attach safety cable
