Tighten both nuts
Note: Guy wires need to be securely mounted to
the building. You can use generic beam clamps
when mounting to I-Beam or steel truss. Lag
I-Bolts can be used when mounting to wood
Glulams. Do not wrap guy wires around the
building structure. Avoid sharp edges.
2.3 Guy Wire Installation
(Fixed Angle Mount Only)
