OPERATION
Towing and shunting coupling
Operating manual MT 32 / 36 119
Towing and shunting coupling
The front and rear tow hitches may only be used by the MT for
towing or otherwise for towing the MT itself.
The maximum towed load is 24,000 kg in manoeuvre mode.
WARNING!
Danger of injury!
There is a danger of considerable injury and damage
when you use towing and shunting couplings to pull
trailers.
X Do not pull trailers with tow bars using towing and
shunting couplings.
X Trailers with tow bars may be coupled only to trailer
equipment approved for this application.
Fig. 27: Towing coupling, front
Fig. 28: Towing coupling, rear <Sattel>
