MAFI MT 36 - Dimensions (Standard Model) <Sattel

TECHNICAL DATA
Dimensions (standard model) <Sattel>
140 Operating manual MT 32 / 36
Dimensions (standard model) <Sattel>
Fig. 1: Dimensions MT 32 / MT 36
Size [mm]
Measurement Wheel base 3,000 Wheel base 3,250
A approx. 2,980 2,980
B 1,488 1,488
C 3,000 3,250
D 690 690
(E) 5,178 5,428
