Magellan eXplorist TRX7 User Manual

TRX7 Hardware.
*available on select models.
**use caution when opening to avoid damaging covers.
***inactive on TRX7.
1. Microphone
2. Touchscreen
3. Lanyard attach point
4. POWER button
5. Volume buttons
6. MUTE button
7. RESET button (unused)
8. Camera button*
9. BACK button
10. HOME button
11. MENU button
12. Cradle screws
13. Speakers
14. Cradle connections
15. Mount Plate
16. Mini-USB Power port**
17. Headphone jack**
18. USB port***
19. Memory card slot
20. Cover latch
21. Camera lens*
1
2
3
4
5
6
7
8
9
10
11
12
13
14
13
15
16
17
18
19
20
21
6

Magellan eXplorist TRX7 Specifications

General

Brand	Magellan
Model	eXplorist TRX7
Category	GPS
Language	English
