Magnetek Enrange Flex EX - Receiver Status and Indications

Flex 8EX EU System Instruction Manual
March 2012
34 of 37
2. Receiver STATUS Light Indication
Type Display Type Indication
1
Fast green blinks Decoding in process
2
Slow green blinks Decoding on standby
3
Two red blinks Receiver MAIN is jammed or defective
4
Fast red blinks Incorrect transmitter serial number/ID code
5
Constant red
Receiver under-voltage, LV output relay
activated
6
No light displayed Decoding microprocessor is defective
3. Receiver SQ Light Indication
Type Display Type (Red) Indication
1
Fast blinks Transmission received
2
Completely off No transmission
3
Blinks intermittently Other radio interference
4. Receiver POWER Light Indication
Type Display Type (Red) Indication
1
On Power to receiver
2
Off No power to receiver
5. Receiver COM Light Indication
Type Display Type (Red) Indication
1
On Power to relay board
2
Off No power to relay board
